Elphel-Eyesis 4π is a panoramic and stereophotogrammetric camera that covers full sphere with the same high resolution, with it's 24 x 5Mpix sensors.
  • Main Features:
    • 4*π (360x180) coverage
    • Calibrated fixed lens to compensate for the lenses distortions
      • 10" (0.1 pix) in the center 80% x 80% area
      • 30" (0.3 pix) maximal error over the full FoV
      • <0.03um/° thermal expansion
    • 26 * 5Mpix, 1/2.5" format image sensors
    • 130 MPix Total resolution
    • 64 MPix Panoramic image resolution after stitching
    • 5 FPS - maximum frame rate
    • Integrated high-precision IMU and GPS
    • Recording to internal SSDs
    • Web Based GUI
    • Free Software and Open Hardware
  • Physical Characteristics:
    • Weight 10 Kg
    • Size 230 x 1350 mm
    • Power Consumption - 50W
    • Weatherproof
Image samples
More Info
How to buy: We are directly accepting orders and ship worldwide. Please contact Elphel for Lead Time and Quotes:
NC353L series camera modules:

NC353L
+ USB, SATA, Serial & Sync ports + Compass
+ GPS receiver
+ IMU
+ Internal 1.8" HDD
+ Calibrated lens
+ Multiplexer board + 2-3 sensors


NC353L series cameras' overview table:

NC353L -PHG -369 -GEO -IMU-GPS -HDD -PHG3 Stereo Hammer
ETH + + + + + + + + +
USB(host) + + + + + + +
SATA + + + + + + +
SYNC/TRIGGER + + + + + + +
CF card support + + + + + +
IMU +
GPS (usb or serial) + +
Compass +
Internal 1.8" HDD + +/-
MUX board 2 sensors 2 sensors
Calibrated lens + +

The default power supply is 48V. 12V modification is available.

Other custom modifications (e.g., add/remove modules) are available for all products. Please send your inquiries to sales@elphel.com or call 801.783.5555x107

Price list     Order



Current sensor's (MT9P006 - 1/2.5", 5MPix, color or mono) Resolution-FPS table



Standard Resolution max. FPS (Color) max. FPS (JP4 RAW)
Full Resolution 2592x1936 10.6 14
2K 2048x1088 23.9 29.5
Full HD (1080p) 1920x1088 25.2 30.9
HD (720p) 1280x720 57.9 60
PAL DV 720x576 100 100
NTSC DV 640x480 126 126
512x512 129 129
320x240 310 310



LineScan mode is available.




Equirectangular projection

Rectilinear corrected

Elphel 353 Camera Brochure

Calibrated sensor front ends and the heptaclops camera blog article


Price list
NC353-PHG is the NC353 series network camera with a calibrated M12 (S-mount) lens and thermally compensated (<0.03um/°) sensor front end intended for use in the area of photogrammetry.

Features:
  • Calibrated fixed lens to compensate for the lenses distortions
    • 10" (0.1 pix) in the center 80% x 80% area
    • 30" (0.3 pix) maximal error over the full FoV
    • <0.03um/° thermal expansion
  • By default the fixed lens is focused on ~4-∞ m
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full HD video (1080p@25fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog

Custom modifications (e.g., 12V) are available for all products. Please send your inquiries to sales@elphel.com or call 801.783.5555x107

Equirectangular projection

Rectilinear corrected

Elphel 353 Camera Brochure

Calibrated sensor front ends and the heptaclops camera blog article

Matching Images Demo
Price list
NC353-369-PHG3 (NC353-369-PHG based) is 3 network cameras with calibrated M12 (S-mount) lenses and thermally compensated (<0.03um/°) sensor front ends intended for use in the area of photogrammetry.

Features:
  • 3xNC353-369-PHGs with known fixed relative orientation between them (provided with the calibration files)
  • Cameras are precisely synchronized
  • Calibrated fixed lens to compensate for the lenses distortions
    • 10" (0.1 pix) in the center 80% x 80% area
    • 30" (0.3 pix) maximal error over the full FoV
    • <0.03um/° thermal expansion
  • By default the fixed lens is focused on ~4-∞ m
  • (3x) 5MPix, 1/2.5", color MT9P006 sensor
  • (3x) Full HD video (1080p@25fps)
  • (3x) Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog

Comparison table for PHG series three-lens cameras:

NC353L-369-PHG3 NC353L-369-PHG3-IMU
USB(host) + +
SATA + +
SYNC + +
IMU - +
GPS - +
Weight 1088g 1120g
Width 110mm 110mm
Height 99mm 113mm
Length 138mm 138mm

Custom modifications (e.g., 12V) are available for all products. Please send your inquiries to sales@elphel.com or call 801.783.5555x107

NC353L is a network camera series 353 capable of streaming high resolution video. Features:
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full resolution: 2592x1944@15fps
  • Full HD video (1080p@25fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog
  • Without lens or adapters:
    • Weight: 215g
    • Width: 44mm
    • Height: 45mm
    • Length: 118mm
Custom modifications (e.g., 12V) are available for all products.
Elphel 353 Camera Brochure
KIT-NC353L
KIT-NC353L-12V
Price list

NC353L-369 is a model 353 series camera capable of recording video and images to the external SATA mass storage device or internal CF cards. Serial port provides access to the root console that simplifies firmware development. Features:
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full resolution: 2592x1944@15fps
  • Full HD video (1080p@25fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog
  • SATA port
  • 2 internal slots for Compact Flash cards
  • Serial console port
  • Opto-isolated I/O port (RJ14 connector) to trigger the camera or synchronize together multiple cameras
  • Without lens or adapters:
    • Weight: 230g
    • Width:  44mm
    • Height: 45mm
    • Length: 118mm
Custom modifications (e.g., 12V) are available for all products.
Elphel 353 Camera Brochure
KIT-NC353L-369
KIT-NC353L-369-12V
Price list

NC353L-369-GEO is a model 353 series camera for making geotagged video and images. Features:
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full resolution: 2592x1944@15fps
  • Full HD video (1080p@25fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog
  • SATA port
  • 2 internal slots for Compact Flash cards
  • Serial console port
  • Opto-isolated I/O port (RJ14 connector) to trigger the camera or synchronize together multiple cameras
  • Ocean Server OS5000-US Digital compass (inside the camera)
  • Available GPS receivers (NMEA 0183):
  • Without lens , adapters and GPS receiver:
    • Weight: 230-235g
    • Width: 44mm
    • Height: 45mm
    • Length: 118mm
Elphel 353 Camera Brochure
Elphel 353 Camera Brochure KIT-NC353L-369-GEO
Price list

NC353L-369-HDD is a model 353 series camera with attached 1.8" for direct recording images/video. It includes:
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full resolution: 2592x1944@15fps
  • Full HD video (1080p@25fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog
  • SATA port
  • 2 internal slots for Compact Flash cards
  • Serial console port
  • Opto-isolated I/O port (RJ14 connector) to trigger the camera or synchronize together multiple cameras
  • 1.8" 120GB ZIF-type HDD (options available)
  • Without lens or adapters:
    • Weight: ~400g
    • Width:  44mm (body), 60mm (HDD enclosure)
    • Height: 45mm (body), +12mm (HDD enclosure)
    • Length: 118mm (body), 90mm (HDD enclosure)
Elphel 353 Camera Brochure
KIT-NC353L-369-HDD
Price list

Stereo/3D camera setup utilises 2 sensors front ends and the 10359 multiplexer board to record synced stereo video. Features:
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full resolution: 2592x1944@7.2fps
  • Full HD video (1080p@15fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog
  • SATA port
  • 2 internal slots for Compact Flash cards
  • Serial console port
  • Opto-isolated I/O port (RJ14 connector) to trigger the camera or synchronize together multiple cameras
  • 2 sensor modules connected to a single system board
  • Stereo pair base: 248.5mm
Elphel 353 Camera Brochure
Price list

Hammer camera setup (MNC354-2B, MNC354-2B-HDD) utilises 2 sensors front ends and the 10359 multiplexer board to record synced stereo video. Features:
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full resolution: 2592x1944@15fps
  • Full HD video (1080p@25fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog
  • SATA port
  • 2 internal slots for Compact Flash cards
  • Serial console port
  • Opto-isolated I/O port (RJ14 connector) to trigger the camera or synchronize together multiple cameras
  • 1.8" 120GB ZIF-type HDD (optional)
  • 2 sensor modules connected to a single system board
Elphel 353 Camera Brochure Price list

NC353L-369-IMU-GPS allows to save a separate log from Inertial Measurement Unit (orientation) and a GPS receiver (USB or serial)
  • 5MPix, 1/2.5", color or mono MT9P006 sensor
  • Full resolution: 2592x1944@15fps
  • Full HD video (1080p@25fps)
  • Ethernet: 100 Mbit/s
  • Recording formats: Quicktime, OGM, JPEG image sequence, JP4 RAW image
  • Free Software and Open Hardware
  • User/developer friendly: HTML, JavaScript, PHP, CGI, C/C++, Verilog
  • SATA port
  • 2 internal slots for Compact Flash cards
  • Serial console port
  • Opto-isolated I/O port (RJ14 connector) to trigger the camera or synchronize together multiple cameras
Elphel 353 Camera Brochure
KIT-NC353L-369-IMU/GPS
Price list
